Steering Column: Removal and Installation: Notes

Fig 1: Identifying Steering Column Removal And Installation

Courtesy of SUZUKI OF AMERICA CORP.

CAUTION:

• Do not exert any axial load or impact to the steering column.
• Do not move the steering gear while the steering column assembly is removed.
• Any time the ignition switch has been removed or installed, the keys must be re-registered in the BCM Refer to SDT operation manual.
