Section 5 (Ignition System (VQ40DE))
>>
Repair Instructions
>>
Spark Plug: Exploded View
Spark Plug: Exploded View
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Spark Plug: Exploded View With Torque Specifications
Courtesy of SUZUKI OF AMERICA CORP.
