Component Description

ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation of switch, and determines which button is operated.

Fig 1: Identifying ASCD Steering Switch

Courtesy of SUZUKI OF AMERICA CORP.

Refer to [ASCD: SYSTEM DESCRIPTION ] for the ASCD function.
