DTC P0111: Intake Air Temperature Circuit Range/Performance: Wiring Diagram

Fig 1: DTC P0111 - Wiring Diagram (Intake Air Temperature Circuit)

G04013690

Courtesy of SUZUKI OF AMERICA CORP.
