Automatic Transaxle Fluid Replacement

1. Inspect transaxle case for evidence of fluid leakage. Repair leaky point, if any.
2. Make sure that vehicle is placed level.
3. Change fluid. For its procedure, refer to A/T FLUID CHANGE .

Fig 1: Identifying Transaxle Case Bolts

Courtesy of SUZUKI OF AMERICA CORP.
