Spark Plug Removal and Installation: Removal

  1. Remove engine cover from cylinder head cover referring to ENGINE COVER REMOVAL AND INSTALLATION .
  2. Remove ignition coil (1) referring to "IGNITION COIL ASSEMBLY (IGNITER AND IGNITION COIL) REMOVAL AND INSTALLATION :".
  3. Remove spark plug (2).
    Fig 1: Removing Spark Plug And Ignition Coil
    G04014285Courtesy of SUZUKI OF AMERICA CORP.
