Home >> Suzuki >> 2004 >> Forenza EX >> Repair and Diagnosis (Single Page) >> Transmission >> Automatic Trans >> Diagnosis >> Diagnostic Trouble Codes Identification >> DTC P0601: Internal Control Module Memory Checksum Error >> Notes

DTC P0601: Internal Control Module Memory Checksum Error: Notes

Fig 1: DTC P0601 Internal Control Module Memory Checksum Error - Diagnostic Wiring Diagram

G00785186

Courtesy of SUZUKI OF AMERICA CORP.
