Home >> Suzuki >> 1988 >> Samurai Base >> Repair and Diagnosis >> Engine Performance >> Ignition System - NIPPONDENSO Electronic >> Overhaul

Ignition System - NIPPONDENSO Electronic: Overhaul

Fig 1: Exploded View of Samurai (Non-Turbo) Distributor

G94276

Courtesy of ISUZU MOTOR CO.
