Seat Position Memory Switch (Models With Seat Position Memory)

  1. Disconnect the ground terminal from the battery sensor, and wait for at least 60 seconds before starting work. Ref. to REPAIR CONTENTS>NOTE>BATTERY
  2. Remove the trim panel front door on the driver's seat side. Ref. to EXTERIOR/INTERIOR TRIM>DOOR TRIM>REMOVAL>FRONT DOOR .
  3. Open the claw using a flat tip screwdriver or similar tool and remove the bracket seat position memory switch.
    G14411568Courtesy of SUBARU
  4. Release the claws, and remove the seat position memory switch assembly.
    NOTE: For an easier procedure, release the claw on one side at a time.
    G13226827Courtesy of SUBARU
