Upper Arm: Removal
CAUTION:
Be careful not to damage the boot of the ball joint.
- Release the parking brake.
- Execute the brake maintenance mode. (CVT model) Ref. to PARKING BRAKE>PARKING BRAKE SYSTEM>OPERATION>BRAKE MAINTENANCE MODE .
- Disconnect the ground terminal from battery sensor. Ref. to REPAIR CONTENTS>NOTE>BATTERY .
- Release the shift lock and shift the select lever to the "N range". (CVT model) Ref. to CONTROL SYSTEMS>SELECT LEVER>REMOVAL .
- Remove the rear wheels. Ref. to WHEEL AND TIRE SYSTEM>TIRE AND WHEEL>REMOVAL .
- Remove the rear suspension assembly. Ref. to REAR SUSPENSION>SUB FRAME>REMOVAL .
- Remove the bolts and nuts, and remove the arm assembly rear upper.
