Fuse Installation
- Delivery mode fuse (30 A) is removed from the position (1) to prevent the battery consumption when vehicles are delivered. Remove the delivery mode fuse from the position (2), and attach the fuse to the position (1). Besides, removing the delivery mode fuse from the position (2) deactivates the control during shipping (delivery mode).
NOTE:
Park the vehicle on a level ground before performing this procedure.
- When the vehicle is delivered, the delivery mode fuse is normally placed in the position (2) as shown in the figure. However, if placed in the position (1), it may indicate that the headlight beam is deviated. In this case, perform the following procedures.
- Park the vehicle on a level ground.
- Turn the ignition switch to OFF and remove the delivery mode fuse from the position (1).
- Install the delivery mode fuse in the position (2) and then turn the ignition switch to ON.
- Turn the ignition switch to OFF, install the delivery mode fuse in the position (1), and start the engine.
