Outback Model

  1. Disconnect the ground terminal from battery sensor. Ref. to BATTERY .
  2. Remove the trim panel assembly rear gate LWR. Ref. to EXTERIOR/INTERIOR TRIM>REAR GATE TRIM>REMOVAL .
  3. Remove the noise suppressor assembly.
    1. Remove the hose assembly rear washer from the hose clamp.
    2. Disconnect the connectors and remove the connector clips and harness clips.
    3. Remove the bolts, then remove the noise suppressor assembly.
      G13952110Courtesy of SUBARU OF AMERICA, INC.
