Reverse Automatic Braking Control Module: Removal

NOTE: The sonar Control Module assembly is installed under the front seat LH. Remove the sonar Control Module assembly after sliding the front seat LH as necessary.
  1. Disconnect the ground terminal from battery sensor. Ref. to REPAIR CONTENTS>NOTE>BATTERY .
  2. Remove the sonar Control Module assembly.
    1. Remove the nut to remove the harness clip.
    2. Disconnect the connector and remove the sonar Control Module assembly.
    G12401704Courtesy of SUBARU OF AMERICA, INC.
