Front impact sensor

CAUTION: Do not reuse mounting bolts.

Fig 1: Front Impact Sensor (With Torque Specification)

G13622626

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T: 13 (1.3, 9.6)
