OUTBACK model

  1. Disconnect the ground terminal from battery sensor. Refer to REPAIR CONTENTS>NOTE>BATTERY .
  2. Remove the trim panel assembly rear gate LWR. Refer to EXTERIOR/INTERIOR TRIM>Rear Gate Trim>REMOVAL .
  3. Remove the garnish assembly rear gate. Refer to EXTERIOR/INTERIOR TRIM>Rear Gate Garnish>REMOVAL .
  4. Remove the license plate light.
    1. Disconnect the connector.
    2. Release the claws from inside the vehicle and remove the license plate light.
    G13622850Courtesy of SUBARU OF AMERICA, INC.
