Subaru
>>
2019
>>
BRZ Series.Gray
>>
Repair and Diagnosis
>>
Restraints
>>
Restraints Control Systems
>>
Seat Belt System
>>
Child Seat Fixing Device (ISO-FIX)
>>
Exploded View
Exploded View
Fig 1: Child Seat Fixing Device (ISO-FIX) Components With Torque Specification
Courtesy of SUBARU OF AMERICA, INC.
Courtesy of SUBARU OF AMERICA, INC.
