Converter Case: Assembly

Install the oil drain plug.
Tightening torque:

70 N.m (7.1 kgf-m, 51.6 ft-lb)
Install the overflow drain plug.
NOTE: Overflow drain plug of differential gear oil is temporarily attached.
Install all plugs.
NOTE: Use new O-rings.

Tightening torque:

T1: 22 N.m (2.2 kgf-m, 16.2 ft-lb)

T2: 22.5 N.m (2.3 kgf-m, 16.6 ft-lb)

Fig 1: Overflow Drain Plugs (With Torque Specification)
Courtesy of SUBARU OF AMERICA, INC.
Install the pitching stopper bracket and transmission radio ground cord.
CAUTION: Be careful not to deform or damage the terminal of transmission radio ground cord.

Tightening torque:

41 N.m (4.2 kgf-m, 30.2 ft-lb)
