VDC OFF Switch: Removal

  1. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work. Ref. to REPAIR CONTENTS>NOTE>BATTERY>GROUND TERMINAL REMOVAL OR INSTALLATION.
  2. Remove the cover assembly - instrument panel LWR driver OUT. Ref. to EXTERIOR/INTERIOR TRIM>Instrument Panel Lower Cover>REMOVAL .
  3. Release the claws and remove the VDC OFF switch.
Fig 1: Locating VDC OFF Switch
G11255160Courtesy of SUBARU OF AMERICA, INC.
