Home
>>
Subaru
>>
2017
>>
BRZ Limited, Automatic Trans
>>
Repair and Diagnosis
>>
Restraints
>>
Restraints Control Systems
>>
Seat Belt System
>>
Child seat fixing device (ISO-FIX)
>>
Exploded view
Exploded view
Fig 1: Exploded View Of Child Seat Fixing Device (ISO-FIX) With Torque Specification
Courtesy of SUBARU OF AMERICA, INC.
Courtesy of SUBARU OF AMERICA, INC.
