Rear Drive Shaft: Installation

WARNING: This page is about a different variant/trim than selected.
  1. Install the rear drive shaft.
    Fig 1: Identifying Rear Drive Shaft
    G10268217Courtesy of SUBARU OF AMERICA, INC.
  2. Select the rear drive shaft shim. < Ref. to ADJUSTMENT , Rear Drive Shaft. >
  3. Install the selected rear drive shaft shims to the rear drive shaft.
  4. Install the extension case. < Ref. to INSTALLATION , Extension Case. >
  5. Install the transmission assembly to the vehicle. < Ref. to INSTALLATION , Automatic Transmission Assembly. >
