Master Cylinder: Inspection

If any damage, deformation, wear, swelling, rust or other faults are found on the cylinder, piston, push rod, nipple, return spring, bleeder screw, seat or hose, replace the faulty part.

Fig 1: Identifying Cylinder, Piston, Push Rod And Bleeder Screw

Courtesy of SUBARU OF AMERICA, INC.
