Amplifier Antenna: Installation

WARNING: This page is about a different car, the 2014 Subaru BRZ. However, it is still accessible from the selected car via links, so may be relevant.

Install the antenna cord SUB-ASSY No. 3.
1. Fasten the three clamps and install the antenna cord SUB-ASSY No. 3.
Install the amplifier antenna ASSY.
1. Attach the two sets of tabs of the amplifier antenna ASSY to the roof.
2. Move the antenna cord so that it sticks out toward the rear of the vehicle, and attach the antenna nut.

  Fig 1: Identifying Antenna Nut And Cord
  Courtesy of SUBARU OF AMERICA, INC.

  Standard value: T=4.5N.m {46kgf.cm} {3.3 ft.lbf}
3. Connect the connector.
Install the roof antenna pole SUB-ASSY. (Refer to INSTALLATION )
Install the roof head lining ASSY. (Refer to INSTALLATION )
Connection of the battery ground terminal
Standard value: T=6.0N.m {61kgf.cm} {4.4ft.lbf}
Settings when connecting/disconnecting battery terminals (Refer to SETTING PROCEDURES AT PARTS REPLACEMENT AND REMOVAL/INSTALLATION )
