Automatic Light Control Sensor: Removal

WARNING: This page is about a different car, the 2014 Subaru BRZ. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnection of the defroster nozzle garnish No. 1 (Refer to COOLER THERMISTOR (SUNLOAD SENSOR) )
  2. Removal of the automatic light control sensor
    1. Disconnect the connector.
    2. Release the 2 tabs, and remove the automatic light control sensor.
      Fig 1: Automatic Light Control Sensor Tabs
      G09492410Courtesy of SUBARU OF AMERICA, INC.
