Unit Inspection
WARNING: This page is about a different car, the 2014 Subaru BRZ. However, it is still accessible from the selected car via links, so may be relevant.
- Parking brake switch ASSY check
- Measure the resistance between the parking brake switch ASSY and the chassis ground.
Courtesy of SUBARU OF AMERICA, INC. RESISTANCE
| Inspection terminals |
Inspection conditions |
Standard value |
| 1(+) - chassis ground |
When shaft is free (ON) |
Less than 1 Ω |
| When shaft is pressed in (OFF) |
10 k Ωor more |
