Section 16 (Entertainment System): Amplifier: Removal

WARNING: This page is about a different car, the 2014 Subaru BRZ. However, it is still accessible from the selected car via links, so may be relevant.

Remove the trunk floor mat.
1. Remove the trunk floor mat.
Remove the amplifier ASSY (with attached bracket).
1. Unhook the clips and remove the rear seat back cover.

  Fig 1: Identifying Amplifier Assy Clip
  Courtesy of SUBARU OF AMERICA, INC.
2. Disconnect the clamps and wiring harness from the stereo component amplifier bracket.

  Fig 2: Identifying Stereo Component Amplifier Bracket Clamps
  Courtesy of SUBARU OF AMERICA, INC.
3. Disconnect the two connectors from the stereo component amplifier.

  Fig 3: Identifying Stereo Component Amplifier Connectors
  Courtesy of SUBARU OF AMERICA, INC.
4. Undo the three nuts and take off the stereo component amplifier ASSY (with attached bracket).

  Fig 4: Identifying Stereo Component Amplifier ASSY Nuts
  Courtesy of SUBARU OF AMERICA, INC.
Remove the amplifier bracket.
1. Undo the four screws and remove the amplifier bracket.

  Fig 5: Identifying Amplifier Bracket Screws
  Courtesy of SUBARU OF AMERICA, INC.
