Unlock Warning Switch Assembly: Removal

  1. Removal of the steering column cover LWR (Refer to INSTALLATION )
  2. Removal of the steering column cover UPR (Refer to INSTALLATION )
  3. Removal of unlock warning switch assembly
    1. Disconnect the connector.
    2. Release the two claws and remove the unlock warning switch assembly.
      Fig 1: Locating Unlock Warning Switch Assembly Connector And Claws
      G10216172Courtesy of SUBARU OF AMERICA, INC.
