At Shift Lock Solenoid

  1. Remove the console box. < Ref. to REMOVAL , Console Box. >
  2. Disconnect the connector.
  3. Remove the connector from the base plate using a flat tip screwdriver.
    Fig 1: Identifying Base Assembly Connector
    G05031915Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the solenoid unit.
    Fig 2: Identifying Solenoid Unit
    G05031953Courtesy of SUBARU OF AMERICA, INC.
  5. Remove the terminal of the solenoid unit, using a flat tip screwdriver.
    Fig 3: Removing Solenoid Unit Terminal Using Flat Tip Screwdriver
    G08544956Courtesy of SUBARU OF AMERICA, INC.
