Front Stabilizer Bar: Components

Fig 1: Front Stabilizer Bar Replacement Components With Torque Specifications (1 Of 2)
G08552796Courtesy of SUBARU OF AMERICA, INC.
Fig 2: Front Stabilizer Bar Replacement Components With Torque Specifications (2 Of 2)
G08552797Courtesy of SUBARU OF AMERICA, INC.
