Front Door Impact Sensor

CAUTION: Do not reuse mounting bolts and nuts.

Fig 1: Locating Front Door Impact Sensor Mounting Bolts And Nuts With Torque Specifications

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque:

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
