Transfer Driven Gear: Assembly

WARNING: This page is about a different variant/trim than selected.
  1. Using the ST, install the ball bearing.

    ST 899580100 INSTALLER

    Fig 1: Installing Ball Bearing Using Special Tool
    G08317927Courtesy of SUBARU OF AMERICA, INC.
