Section 14 (Exhaust System (H6DO)): Muffler: Installation
WARNING: This page is about a different variant/trim than selected.
Install in the reverse order of removal.
NOTE:
- Use a new gasket and self-locking nut.
- After assembling, degrease the lubricant which was applied to the cushion rubber while removing/installing.
Tightening torque:
48 N.m (4.9 kgf-m, 35.4 ft-lb)
