DTC B2785 Lin Communication Error: Wiring Diagram

Push button start system < Refer to appropriate SYSTEM WIRING DIAGRAM. >

Fig 1: Push Button Start System - Wiring Diagram (Lin Communication Error)
G08585653Courtesy of SUBARU OF AMERICA, INC.
