Trunk Opener Switch: Removal: Notes

NOTE: The trunk opener button is integrated with the VDC OFF switch.
  1. Remove the instrument panel lower cover. Refer to REMOVAL .
  2. Release the claws and remove the trunk opener button.
    Fig 1: Identifying Trunk Opener Button Claws
    G06653908Courtesy of SUBARU OF AMERICA, INC.
