Third Seat Belt

Fig 1: Exploded View Of Third Seat Belt

G06341024

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque: N.m (kgf-m, ft-lb)

T1: 30 (3.1, 22)

T2: 38 (3.9, 28)
