Fuel Filler Pipe: Disassembly

  1. Remove the shut valve from the fuel filler pipe. < Ref. to REMOVAL , Shut Valve. >
  2. Remove the evaporation pipe from the fuel filler pipe.
    Fig 1: Locating Evaporation Pipe Mounting Bolts Of Fuel Filler Pipe
    G07681809Courtesy of SUBARU OF AMERICA, INC.
