Front Under Cover: Installation

WARNING: This page is about a different car, the 2012 Subaru Outback and 2012 Subaru Legacy. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Install the under cover so that the under cover front end (b) comes inside of the front bumper face (a).

Fig 1: Identifying Proper And Improper Bumper Installation Position

Courtesy of SUBARU OF AMERICA, INC.

Install each part in the reverse order of removal.

Tightening torque:

17.5 N.m (1.78 kgf-m, 12.9 ft-lb)
