Torque Converter And Case
WARNING: This page is about a different variant/trim than selected.
Courtesy of SUBARU OF AMERICA, INC.
Tightening torque: N.m (kgf-m, ft-lb)
T1: 18 (1.8,13.3)
T2: 41 (4.2,30.2)
T3: 44 (4.5,32.5)
(Aluminum gasket, silver)
70 (7.1,51.6)
(Copper gasket, brown)
70 (7.1,51.6)
(Metal gasket, black)
