General Information (STI): Notices: Note: Towing

Avoid towing vehicles except when the vehicle cannot be driven. When towing other vehicles, pay attention to the following to prevent hook or vehicle damage resulting from excessive weight.

Precautions

TOWING PRECAUTIONS

Towing Precautions AWD
MT
Lifting up four wheels (On a trailer)
G05667423Courtesy of SUBARU OF AMERICA, INC.
Towing the vehicle after lifting up all four wheels is a basic rule for AWD model.
CAUTION: When carrying the vehicle onto a car carrier truck, refer to "LOADING ONTO CAR CARRIER TRUCK". Ref. to LOADING ONTO CAR CARRIER TRUCK , NOTE, Note.
Rope
G05667424Courtesy of SUBARU OF AMERICA, INC.
Check if both front and rear wheels are rotated normally.
Raising the front wheels
G05667425Courtesy of SUBARU OF AMERICA, INC.
Prohibited for full-time AWD model. X
Lifting up the front wheels
G05664774Courtesy of SUBARU OF AMERICA, INC.
Prohibited, due to damage on bumper, front grille, etc. X
◦ mark: OK, X mark: Prohibited
CAUTION:
  • When towing is performed, position the shift lever to neutral.
  • Do not lift up the rear wheels to avoid unsteady rotation.
  • Turn the ignition key to "ACC", then check the steering wheel moves freely.
  • Release the parking brake to avoid tire dragging.
  • Since the power steering does not work, be careful for the heavy steering effort. (When engine is stopped)
  • Since the servo brake does not work, be careful that the brake is not applied effectively. (When engine is stopped)
  • In case of the malfunction of internal transmission or drive system, lift up four wheels (on a trailer) for towing.
