SPECIAL TOOL
| ILLUSTRATION | TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|---|
| 18482AA010 | CARTRIDGE | Troubleshooting for electrical system. | |
| 22771AA030 | SUBARU SELECT MONITOR KIT | Troubleshooting for electrical system. |
- TEST HARNESS DTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG060 TEST HARNESS D Used when measuring voltage and resistance of front seat belt buckle switch. - TEST HARNESS FTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FC010 TEST HARNESS F Used when measuring voltage and resistance of airbag module harnesses. - TEST HARNESS HTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor. - TEST HARNESS NTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module and seat belt pretensioner. - TEST HARNESS PTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of driver's airbag module harness and passenger's airbag module harness. - TEST HARNESS QTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module. - TEST HARNESS UTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG000 TEST HARNESS U Used when measuring voltage and resistance of airbag control module. - TEST HARNESS VTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor. - TEST HARNESS YTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 28299AG040 TEST HARNESS Y Used for diagnosing seat belt buckle switch. - TEST HARNESS ABTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA000 TEST HARNESS AB Used when measuring voltage and resistance of occupant detection system. - TEST HARNESS ACTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA010 TEST HARNESS Used for diagnosing a failure of the seat belt tension sensor. - TEST HARNESS ADTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA020 TEST HARNESS AD Used when measuring voltage and resistance of seat belt tension sensor. - TEST HARNESS AETOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA030 TEST HARNESS AE REMARKS - Used for diagnosing a failure of the seat belt
- Used together with the test harness Y.
- AIRBAG RESISTORTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module.
