Special Tool
SPECIAL TOOL
| ILLUSTRATION | TOOL NUMBER | DESCRIPTION | REMARKS |
|---|---|---|---|
| 18482AA010 | CARTRIDGE | Troubleshooting for the electrical system. | |
| 22771AA030 | SUBARU SELECT MONITOR KIT | Troubleshooting for the electrical system. |
- TEST HARNESS DTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG060 TEST HARNESS D Used when measuring the voltage and resistance of the front seat belt buckle switch. - TEST HARNESS UTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG000 TEST HARNESS U Used when measuring voltage and resistance of airbag control module. - TEST HARNESS YTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 28299AG040 TEST HARNESS Y Used for diagnosing the seat belt buckle switch. - TEST HARNESS ABTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA000 TEST HARNESS AB Used when measuring voltage and resistance of occupant detection system. - TEST HARNESS AETOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA030 TEST HARNESS AE TEST HARNESS Y ADAPTER HARNESS Used for diagnosing the seat belt buckle switch. - TEST HARNESS ACTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA010 TEST HARNESS AC Used for diagnosing the seat belt tension sensor. - TEST HARNESS ADTOOL NUMBER DESCRIPTION CHART
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA020 TEST HARNESS AD Used when measuring voltage and resistance of the seat belt tension sensor.
