Side Turn Signal Light Assembly: Removal

1. Disconnect the ground cable from battery.
2. Remove the scalp caps. < Ref. to REPLACEMENT , Scalp Cap. >
3. Remove the mirror. < Ref. to REPLACEMENT , Outer Mirror. >
4. Disconnect the harness connector, remove the 3 mounting screws and then remove the side turn signal light assembly.

Fig 1: Disconnecting Harness Connector

Courtesy of SUBARU OF AMERICA, INC.
