Upper Inner Trim: Installation

WARNING: This page is about a different car, the 2005 Subaru Baja. However, it is still accessible from the selected car via links, so may be relevant.

Install in the reverse order of removal.

CAUTION: Be sure to securely hook pawls of inner trim panel to body flange.

NOTE: When installing center pillar upper trim and front pillar upper trim, be sure to set front mole as shown in Fig 1 .

Fig 1: Installing Center Pillar Upper Trim And Front Pillar Upper Trim

Courtesy of SUBARU OF AMERICA, INC.
