Side Retainer

  1. Remove the O-ring.
    Fig 1: Removing O-Ring
    G03751117Courtesy of SUBARU OF AMERICA, INC.
  2. Remove the oil seal.
    NOTE: Do not reuse the oil seal. Prepare a new oil seal.
    Fig 2: Removing Oil Seal
    G03751118Courtesy of SUBARU OF AMERICA, INC.
