Front Accessory Power Socket: Removal

  1. Disconnect ground cable from battery.
  2. Remove center panel. Refer to REMOVAL  , Radio.
  3. Disconnect harness connectors and remove front accessory power socket.
    Fig 1: Removing Front Accessory Power Socket
    G03510240Courtesy of SUBARU OF AMERICA, INC.
