Switch Back Gate: Installation

Install in the reverse order of removal.

Fig 1: Mounting Weatherstrip By Aligning Silver Line Mark With Back Panel Tray Center Bolt

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque:

27.5 N.m (2.80 kgf-m, 20.3 ft-lb)
