MPT Model

  1. Set the select lever to "P" range.
  2. Using a plastic hammer, install reduction driven gear assembly and new washer, and tighten new drive pinion lock nut.

    Tightening torque:

    100 N.m (10.2 kgf-m, 73.8 ft-lb)

    Fig 1: Tightening Drive Pinion Lock Nut
    G00956495Courtesy of SUBARU OF AMERICA, INC.
  3. After tightening, stake the lock nut securely.
  4. Combine the transmission case with the extension case, and install rear vehicle speed sensor. < Ref. to INSTALLATION <-- , Extension Case -->.>
  5. Install the transmission assembly to vehicle. < Ref. to INSTALLATION <-- , Automatic Transmission Assembly -->.>
