LH Side

  1. Release the fuel pressure. Refer to FUEL .
  2. Open the fuel filler flap lid and remove the fuel filler cap.
  3. Disconnect the ground cable from battery.
    Fig 1: Disconnecting Ground Cable From Battery
    G00928838Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the intake manifold. Refer to INTAKE MANIFOLD .
  5. Disconnect the connector from the fuel injector.
  6. Remove the screw and remove the fuel injector.
    Fig 2: Removing Fuel Injector
    G00928839Courtesy of SUBARU OF AMERICA, INC.
