Home >> Subaru >> 2003 >> Outback L.L. Bean Edition >> Repair and Diagnosis >> Accessories & Equipment >> Infotainment >> Entertainment Systems >> Cigarette Lighter >> Removal

Cigarette Lighter: Removal

  1. Disconnect ground cable from battery.
  2. Remove center panel. < Ref. to REMOVAL  , Radio Body.>
  3. Disconnect harness connectors and remove cigarette lighter.
    Fig 1: Removing Cigarette Lighter
    G02872429Courtesy of SUBARU OF AMERICA, INC.
