Freeze Frame Data

NOTE:
  • Data stored at the time of trouble occurrence is shown on display.
  • Each time trouble occurs, the latest information is stored in the freeze frame data in memory.
  • If freeze frame data is not properly stored in memory (due to a drop in ABSCM power supply, etc.), a DTC, preceded by a question mark "?", appears on the select monitor display. This shows it may be an unreliable reading.
  • In case of no trouble code, the initial value of freeze frame data will be displayed.
Fig 1: Freeze Frame Data Description Chart
G02873210Courtesy of SUBARU OF AMERICA, INC.
