Transfer Case

WARNING: This page is about a different variant/trim than selected.
  1. Install the oil guide to transfer case.
    1. Tightening torque:  6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
    2. Fig 1: Installing Oil Guide To Transfer Case
    G02093654Courtesy of SUBARU OF AMERICA, INC.
  2. Install the reverse check sleeve assembly to transfer case. Refer to INSTALLATION , Reverse Check Sleeve.
